ANTOP AT-402B Flat-Panel Smartpass Amplified Outdoor/Indoor TV Antenna with High Gain and Built-in 4G LTE Filter -60/70 Miles Long Range Multi-Directional Reception - 40ft Detachable Coaxial Cable
Product Description
Redesigned to match similar gain of traditional bulky, unsightly mechanical antennas, the AT-402B with multi-direction, High Gain reception and Smartpass Technology amplifies your range, from 0, 60 and 70 miles from broadcast origination source! Assuring you more channel reception and less blind spots.
FEATURES:
Digital technology allows High Gain reception
Built in 4G LTE Filter blocks unwanted 3G/4G interference
Smartpass Amplifier System, for balanced short & long range reception
Quick & Easy Install, Set-Up
Perfect for indoor, outdoor & mobile use
Sleek durable design, anti UV & waterproof exterior
TECHNICAL SPECIFICATION
Frequency Range: 87.5-230MHz, 470-700MHz
Receiving Range: VHF/UHF
Gain: 12.5dB or 29dB
Max Output level: 100dBuV
Impedance: 75Ω
Noise figure: ≤2.5dB
Reception Pattern: Multi-directional
Polarization: Horizontal/Vertical
Smart Switch - Off: non-amplified
Smart Switch - On: amplified with DC 12V via power adapter
ANTOP’s Exclusive Smartpass Amplifier System & 4G/LTE Filter
SMARTPASS AMPLIFIER SYSTERM- No hesitation any more on deciding between a short range and long range antenna! ANTOP’s Smartpass Amplifier System, an exclusive technology offered only by ANTOP, uses an all-in-one design to allow an easier connection and more possibilities in different receiving ranges.
- Switch-off: Yellow light indicates short range reception
- Switch-on: Green light indicates long range reception
4G/LTE FILTER – ANTOP was the first antenna manufacturer to include a built in filter to block 3G and 4G wireless signals to ensure noise-free digital TV reception.
Quick & Easy Set-up
1) Connect the coaxial cable with the antenna and Power Inserter.
2) Plug the other end of Power Inserter into a TV.
3) Connect the Power Inserter to power.
4) Switch the Power Inserter Off->Adjust the antenna positioning-> scan the channels.
5) Switch the Power Inserter On->Adjust the antenna positioning-> scan the channels
6) Enjoy your TV shows.
NOTE: The antenna can work as passive if to exclude the Power Inserter in connection. The antenna must be powered for function on amplifier!
Multiple Installation Options
Full mounting kit included for easy installation.
1) Roof top
2) Balcony
3) Table standing
WHAT’S IN THE BOX
1) Antenna
2) Power Inserter with Smart Switch
3) AC/DC Power Adapter
4) Indoor Stand
5) 40ft Coaxial Cable (1 pcs)
6) Pole Mounting Kit
7) Instruction/User Manual
8) Instrucciones de Instalación en Español
Antenna Effectiveness
Obstacles such as trees, buildings, and mountains can impact an antenna’s performance.
Position the antenna to face broadcast tower, in a location as high as possible, with a clear path as possible between the antenna and broadcasting towers.
