Features : A variety of input connectors - 4 × 12G-SDI connectors with loop-through - 1 × HDMI 2.0 connector with loop-through - 1 × DP 1.2 connector 1 × replaceable input card Input card can be DVI or HDMI (default) card. 16 × Neutrik Ethernet ports and 4 × OPT ports − The loading capacity can be up to 8.8 million pixels − 4 × 10G OPT outputs with copy and hot backup modes 6 × layers, 1 × OSD, 1 × LOGO, and 1 × BKG 2 × layers up to 4K×2K, 4 × layers up to 2K×1K Layer scaling supported OSD supports 4K×2K resolution, cropping, opacity, dynamic or static images and position settings. Layer opacity adjustment, irregular layers, layer mask, and layer copying, mirroring and flipping supported Layer priority adjustment by z-order Up to 8K output width or height of a single device Multiviewer settings Monitor the input sources, PVW, PGM, or perform mixed monitoring. Quick and advanced screen configurations With the built-in smart platform Master VI, LED screen configuration and layer configuration can be easily performed using the connected mouse, keyboard and monitor. 10-bit processing of the input source HDR function to make images finer and smoother (NovaStar A8s or A10s Plus receiving card required) Low latency output The delay from the input source to receiving card can be as low as 1 frame when the low latency and synchronization functions are turned on and the data runs vertically on the screen
About this item Input Voltage ：AC 100 V-240 V, 50/60 Hz Temperature：-10℃-60℃ Overall Consumption ：180W Humidity ：0-95% Net Weight ： 21Kg Gross Weight ： 42Kg Certifications：FCC, IC, UL/CUL, CB, CE, RoHS, EAC, KC, RCM, PSE
› See more product details
