Features:1.This amplifier has a wide frequency range:gain stability, low noise figure, dynamic range .2.Increase the communication distance:Advantage, especially for a variety of RF receiver front-end circuit, increase the communication distance!3.Widely used in shortwave: FM radio, remote control receiver, cable TV signal amplifier, Beidou, GPS satellite navigation, 2.4G Bluetooth, WIFI receiver RF front end need low noise small signal radio frequency amplification place.4.The board layout is reasonable: beautiful, little current sound.5.It's low in properties :can be a perfect match various circuits as ideal amplifier buffer amplifiers.Descriptions:1.This is a 10 - 6000MHz RF Radio Frequency Broadband Signal Amplifier Board.2.Uses the high quality material, stable and reliable performance.Specifications:Color:GreenFrequency range: 10-6000MHzrtion loss: 0.3dB@512MHz 0.45dB@1575MHzLarge voltage: 50VHigh current: 500mARF connector: SMA-K (outer screw inner hole)System impedance: 50 ohmsDimensions: 33mmx33mm without connectorDC: External DC power supplyRF: RF signal terminal (this port can only transmit RF signals)RF+DC: RF DC offset (this port can transmit RF and DC offset)GND-: common ground terminal for DC power supplyVCC+: DC power supply terminalPackage included: 1 x RF And Microwave DC Bias DC Feeder Module 10-6000MHz Notes:1. Due to the difference between different monitors, the picture may not reflect the actual color of the item. We guarantee the style is the same as shown in the pictures.2. Please allow slight dimension difference due to different manual measurement.
This amplifier has a wide frequency range:gain stability, low noise figure, dynamic range .
Increase the communication distance:Advantage, especially for a variety of RF receiver front-end circuit, increase the communication distance!
Widely used in shortwave: FM radio, remote control receiver, cable TV signal amplifier, Beidou, GPS satellite navigation, 4G Bluetooth, WIFI receiver RF front end need low noise small signal radio frequency amplification place.
The board layout is reasonable: beautiful, little current sound.
It's low in properties :can be a perfect match various circuits as ideal amplifier buffer amplifiers.
