WAVLINK Dual 4K USB C Universal Laptop Docking Station, Dual 4K@60Hz & Single 5K@60Hz Display,2xHDMI & Display Port,6 USB 3.0,Gigabit Ethernet,Audio for Windows & Chrome OS
Product Description
Features
Ultra-HD 5K (5120 x 2880@60Hz) single display
DisplayPort+DisplayPort output resolutions up to 5120 x 2880@60Hz single display when using dual DisplayPort). Provide you the highest resolution video with an incredible 14.7 million pixels give you amazing feast vision, showing every details clearly as like be personally on the scene. It also helps to improve operational efficiency on images and video editing.
Dual Video 4K@60HZ
the maximum resolution up to 3840x2160 (UHD) if both video outputs are being used.
Connection way: HDMI+display port or HDMI+HDMI or display port+display port, which will greatly help you facilitate high-resolution works, graphically intensive images, video editing, CAD drawings, medical imagery and more.
* On HDMI output make sure your HDMI cable is capable of 4K @ 60Hz. For Display port make sure your monitor supports DP 1.2 and make sure monitor settings are configured to use DP 1.2 and not 1.1
Gigabit Ethernet Port
Gigabit Ethernet coming with a RJ-45 port over 10/100/1000Mbps speed, you can quickly download large files, stream movies, and more.
* Ethernet port requires full-duplex network infrastructure.
Six USB 3.0 Ports
USB 3.0 ports for super transfer speed up to 5Gbps and 900mA of power, you can connect your usb peripherals or usb stick to solve external USB devices and high-speed file transfer for home office workers.
* 2.4Ghz wireless devices such as wireless keyboard/mouse receivers, Bluetooth and WiFi adapter, may not work in the USB 3.0 ports on the dock. A short USB 2.0 extension cable to move the wireless device further from the dock will often resolve the issue.
Driver
This item has DL-6950 chipset which made by Displaylink. Please go to download the latest driver from displaylink
System Compatible
Processor: 1.2GHz or faster with support SSE2
RAM: 2GB for 1 DisplayLink display. 4 GB or more recommended for 2 or more DisplayLink displays
-Windows XP ( 32-bit)/ Vista /7 / 8 / 8.1 / 10
-Mac OS 10.6 to 10.13.3
- 2015 and later Chromebooks
- Android 5.x Tablet or Smartphone
Not Compatible With:
-Windows XP (64-bit ), Linux/Unix or ARM based Windows operating systems (such as Surface RT).
Please download the latest drive form displaylink:
www.displaylink.com/downloads
Configuration modes
Extend Mode- Extend your working desktop with split-screen presentation to enhance work efficiency.
Mirror Mode - You can conveniently share and enjoy videos or slideshows on the big and high definition screen.
Primary or Replace mode: This mode is used if wanting to use your laptop with the lid closed.
Attention
-Max 5K (5120 x 2880@60Hz) resolution only via dual Display Ports with 5K monitor.
-Does not provide power attached to host laptop or tablet; the host system will still require its power cable/charger.
-Cannot be mixed with non-DisplayLink USB graphics adapters and drivers (e.g. MCT, j5, or SMSC).
-This docking station is not compatible with the graphics card on notebook PC (NVIDIA GeForce).
-On HDMI output make sure your HDMI cable is capable of 4K @ 60Hz.
-Supports DP 1.2 and make sure monitor settings are configured to use DP 1.2 and not 1.1.
In The Box
- 1 x USB C Dual 4K Universal Dock station
- 1 x 100W power adapter
- 1 x USB Type C to C Cable
- 1 x USB Type C to A cable
- 1 x CD Driver
- 1 x Instruction Manual
From the brand
-
Found in 2003, WAVLINK owns the expertise in comprehensive IT peripherals as well as being a worldwide leading manufacturer. Design, develop, and manufacturing all its product. As one of the only true designers & manufacturers in the industry, WAVLINKoffers high quality design products backed by the service and support that consumer demand.The company distributes products throughout North and South America, Europe, Asia-Pacific.
-
